Corsair FRAME 5000D WORKSTATION Modular Mid-Tower PC Case

Modular mid-tower engineering for workstation-class builds | Expansive cooling and radiator support | Reverse-connector motherboard compatibility | Tempered glass showcase panel | Comprehensive hardware accessory kit included

Quick Specs

• Achieve extreme build flexibility with support for Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, and SSI-EEB motherboards.
• House the most powerful GPUs with up to 450mm of clearance and a dedicated anti-sag stabilisation arm.
• Dominate thermal management with radiator support up to 420mm across the front, top, and side simultaneously.
• Connect everything instantly with front I/O including USB 3.2 Gen 2×2 Type-C and four USB 3.2 Gen 1 Type-A ports.
• Build with confidence across 9 expansion slots and 42mm of rear cable-routing space for a clean, professional finish.

The Chassis Built for Serious Workstation Builds

The Corsair FRAME 5000D WORKSTATION is a mid-tower chassis engineered for builders who refuse to compromise. Whether you are assembling a content-creation powerhouse, a professional rendering rig, or a high-end workstation, this case gives you the room, the structure, and the flexibility to realise your vision. With support for motherboards from Mini-ITX all the way up to E-ATX, SSI-CEB, and SSI-EEB — including reverse-connector designs — the FRAME 5000D is ready for whatever platform your build demands.

Cooling Headroom That Matches Your Ambition

Tired of cramped cases that bottleneck your cooling options? The FRAME 5000D opens up an extraordinary range of liquid and air cooling configurations. Radiators up to 420mm are supported at the front, top, and side simultaneously, while a 175mm CPU cooler height clearance accommodates the tallest tower coolers on the market. Fan positions across the front, top, rear, and bottom — accepting 120mm, 140mm, and 200mm fans — mean there is no shortage of airflow paths for even the most thermally demanding workstation hardware. The included InfiniRail fan mount system makes repositioning fans and radiators straightforward and tool-friendly.

A GPU-Ready Interior Engineered for Heavy Hardware

With a maximum GPU length of 450mm (425mm with fans installed), the FRAME 5000D accommodates the largest graphics cards available. A dedicated GPU anti-sag stabilisation arm and rubber spacer are included in the box to keep heavy dual-slot and triple-slot cards securely positioned over time. Eight horizontal and three vertical PCI expansion slots give you the configuration freedom for multi-card and high-expansion workstation setups, while vertical mount support — with a riser card available separately — lets you showcase your GPU through the tempered glass side panel.

A Clean Build Platform with Pro-Grade Connectivity

The FRAME 5000D keeps cable management organised with 42mm of rear cable-routing space, RapidRoute cable management, and 12 zip ties included in the accessory kit. Dust filters on the front, side, and bottom protect your components in long-term operation. The front I/O panel delivers four USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2×2 Type-C port, and a combined mic/headphone jack for day-to-day connectivity. The 3D-Y Airflow Steel front panel and steel side panels — with sound dampening material — round out a chassis that is as practical as it is purposeful.

Features

• Supports Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm), SSI-CEB, and SSI-EEB motherboards, including reverse-connector designs.
• Radiator support up to 420mm at the front, top, and side — with 120mm and 140mm rear radiator support as well.
• Maximum GPU length of 450mm (425mm with fans installed); GPU anti-sag stabilisation arm and rubber spacer included.
• 175mm maximum CPU cooler height clearance for compatibility with large tower coolers.
• 8 horizontal + 3 vertical PCI expansion slots for multi-GPU and high-expansion workstation configurations.
• Front I/O: 4x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2×2 Type-C, 1x combo mic/headphone jack.
• 42mm rear cable-routing space with RapidRoute cable management system.
• Dust filters on the front, side, and bottom; tempered glass left side panel for interior visibility.
• Steel side panels with sound dampening material for reduced acoustic output.
• Pre-installed 12x InfiniRail fan mounts for flexible, tool-friendly fan and radiator positioning.

Specifications

• Brand: Corsair
• Motherboard Support: Mini-ITX, Micro-ATX, ATX, E-ATX
• Side Panel: Tempered Glass
• Included Fans: 4
• Max GPU Length: 450 mm
• Max CPU Cooler Height: 175 mm
• Radiator Support:
  • Front: 240mm, 280mm, 360mm, 420mm,
  • Top: 240mm, 280mm, 360mm, 420mm,
  • Rear: 120mm, 140mm,
  • Side: 240mm, 280mm, 360mm, 420mm,
  • PSU Shroud: None
• Front I/O:
  • 4x USB 3.2 Gen 1 Type-A,
  • 1x USB 3.2 Gen 2
  • x2 Type-C,
  • 1x Power Button,
  • 1x Combo Mic / Headphone
• RGB Lighting: false
• PSU Included: false

What’s in the Box

• 1 x Corsair FRAME 5000D WORKSTATION Mid-Tower PC Case – Black
• 1 x Side Fan Mounting Bracket
• 1 x Reverse Connector Magnetic Strip
• 12 x InfiniRail Fan Mounts (pre-installed)
• 1 x Front I/O Adapter
• 12 x Zip Ties
• 16 x QuikTurn Fan Screws
• 8 x Long Fan Screws
• 18 x Motherboard / HDD Screws
• 16 x SSD Screws
• 1 x Spare Motherboard Standoff
• 2 x Vertical Mount Standoffs
• 12 x InfiniRail Fan Mount Lock Screws
• 1 x Anti-Sag Arm Rubber Spacer
• 1 x GPU Anti-Sag Stabilisation Arm Mini Mount
• 1 x CORSAIR Side Cable Shroud Sticker

Why Corsair

Corsair has built its reputation on performance-focused PC components trusted by builders, professionals, and enthusiasts worldwide. From their acclaimed cooling solutions to their rigorously engineered chassis, Corsair delivers the quality and thoughtful design that South African PC builders demand — making the FRAME 5000D a natural centrepiece for any serious workstation build.
